With DesignSpark Mechanical there are three methods for modeling - from scratch, by selecting components from the DesignSpark library and using them as the basis for a design, or a combination of the two. With these basic 3D tools, I realized that I had the ability to conceptually model many types of electronic panels and enclosures. Objects can be added (or merged) together and subtracted (or split) from each other, creating new modified objects that better suit design needs. Combine – This tool merges and splits solids and surfaces for altering objects.The fill operation in DesignSpark Mechanical is relatively simple compared with most other feature-based modelers. Fill – This tool is used for selecting a model region and then filling it with the surrounding solid or surface.Move – This tool is used for selecting and moving faces, solids, surfaces, or objects in a 2D or 3D model.
This tool sets DesignSpark Mechanical apart from more complex history-based parametric modelers.
Pull – This the primary tool for creating and editing models in DesignSpark Mechanical for extruding, offsetting, revolving, sweeping, drafting, and blending edges and faces. Refining a design using DesignSpark Mechanical’s 2D and 3D editing tools.ĭesignSpark Mechanical has comprehensive 2D and 3D sketching capabilities, as well as the following basic tools for creating and editing 3D geometry:. Sketching and pulling to create parts, or importing and opening existing part models from other modeling software, or from the RS Components/Allied Electronics parts library. Using DesignSpark Mechanical consists of the following three basic steps: I found DesignSpark Mechanical to be a very capable mechanical design tool for non-specialists and was pleasantly surprised at its capabilities and potential.ĭesignSpark Mechanical is built on SpaceClaim Engineer, 3D design software that offers a short learning curve along with a direct modeling approach that lets you directly pull and move geometry for design optimization. I was interested in experiencing how a mechanical design product would translate for electronics designers and conceptual design. But, I recently discovered a unique mechanical design product, DesignSpark Mechanical, tailored for engineers whose primary role is electronics design, and secondary role is mechanical design for creating panels, enclosures, and machines. As our readers know, there is no shortage of mechanical CAD tools available for trained mechanical designers.
